MANUAL HYDROGRAPHICS WATER TRANSFER PRINTING MACHINES
The dipping tank is the heart of the water transfer printing process. It is a large, water-filled container where the hydrographic film is placed on the surface. The tank maintains a consistent water temperature and provides a controlled environment for the immersion of objects.
The dipping tank is the heart of the water transfer printing process. It is a large, water-filled container where the hydrographic film is placed on the surface. The tank maintains a consistent water temperature and provides a controlled environment for the immersion of objects.
While a paint booth is not mandatory for every water transfer printing setup, it can significantly contribute to the quality and efficiency of your hydrographic printing process.Ensures proper ventilation to disperse fumes generated during the hydro dipping process
A drying system, often comprising heaters or blowers, helps accelerate the drying process of the object after it's been dipped and coated. Proper drying is crucial to prevent smudging, running, or defects in the final appearance.
MANUAL HYDRO DIPPING TANKS
Hydrographics Tanks plays a critical role in the hydrographic printing process by facilitating the hydration of the hydrographic film before activation. By ensuring that the film is fully hydrated and ready for application, it helps maintain the quality and integrity of the printed design, ultimately contributing to the success of the hydro dipping process.
Hydration of the Hydrographic Film
Hydration of the hydrographic film is crucial for achieving smooth application. Proper soaking ensures the film activates correctly, allowing for flawless adhesion to the object's surface.
Preparation for Activation
Preparation for activation involves ensuring the surface is clean and primed, setting up the hydro dipping film, and adjusting the water temperature for optimal adhesion and results.
Ensuring Optimal Results
We prioritize precision quality to ensure optimal results in every hydro dipping project. Our advanced technology and expert support guarantee flawless finishes and long-lasting durability for your dipped items.
Facilitating the Dipping Process
We streamline the hydro dipping process with advanced tools and materials, ensuring efficient and flawless results. Our products are designed to simplify each step, from preparation to finishing.
MODEL TANKS
POPULAR MODELS MANUAL DIPPING TANKS
The 6 feet hydro dipping tank strikes an excellent balance between size and capability. It accommodates a range of objects for dipping, making it a popular choice. Its standout features include adjustable rack systems, efficient water circulation, and rapid heating technology. This tank offers versatility and efficiency, enabling users to achieve consistent results.
Specifications
- Size: 4 feet
- Material: Stainless Steel (304 Grade)
- Pump: 0.5 Hp
- Heating: 1500 Watts
- Training: N/A
- Warranty: 1 Year
The 6 feet hydro dipping tank strikes an excellent balance between size and capability. It accommodates a range of objects for dipping, making it a popular choice. Its standout features include adjustable rack systems, efficient water circulation, and rapid heating technology. This tank offers versatility and efficiency, enabling users to achieve consistent results.
Specifications
- Size: 6 feet
- Material: Stainless Steel (304 Grade)
- Pump: 1 Hp
- Heating: 3000 Watts
- Training: 3 Day (15 hours Approx.)
- Warranty: 1 Year
The 8 feet hydro dipping tank stands out as a premium solution for large-scale hydrographic projects. Its spacious design accommodates oversized objects and allows for batch dipping, increasing productivity and efficiency. This tank is perfect for industrial applications and large-scale production environments, offering unparalleled performance and reliability.
Specifications
- Size: 8 feet
- Material: Stainless Steel (304 Grade)
- Pump: 1.5 Hp
- Heating: 6000 Watts
- Training: 3 Days (15 hours Approx.)
- Warranty: 1 Year
COMBO MINI TANK
INTRODUCTION
HERE ARE SOME OF THE STANDOUT FEATURES
Introducing our innovative Combo Mini Tank, a versatile solution that combines dipping and washing systems into one compact machine, streamlining the hydrographic process like never before.
Dual Functionality: The Combo Mini Tank seamlessly integrates dipping and washing functionalities in a single unit, optimising workflow efficiency and saving valuable workspace.
Space-Saving Design: Its compact footprint makes it ideal for workshops with limited space, allowing users to maximise their working area while enjoying the benefits of both dipping and washing capabilities.
Durable Construction: Built with high-quality materials and components, the Combo Mini Tank guarantees long-lasting performance and reliability, making it a valuable investment for hydrographic professionals and enthusiasts alike.
Easy Maintenance: The tank features easy-to-clean surfaces and accessible components, simplifying maintenance tasks and minimising downtime, ensuring uninterrupted operation.
DISCOVER OUR MAIN FEATURES FOR UNMATCHED QUALITY
Introducing our Dipping Tank with an innovative Dipping Arm System, revolutionising the hydro dipping process with enhanced precision and efficiency. The dipping arm system offers unparalleled control and stability, ensuring smooth and uniform film application on various objects. Designed for versatility and ease of use, this dipping tank with the dipping arm provides an exceptional dipping experience for users of all skill levels.
SOME ESSENTIALS MATERIALS
ARE YOU INTERESTED IN STARTING A HYDRO DIPPING VENTURE BUT UNCERTAIN ABOUT WHERE TO BEGIN?
Films
You will need hydro dipping film to transfer the design onto the item.
Activators
Activator is a chemical solution that is used to dissolve the film and activate the ink.
Spray Gun
A spray gun is used to apply the hydro dipping film activator onto the water surface.
Air Compressor
It powers the spray gun and provides air pressure to apply the hydro dipping film.
MANUAL WASH BOOTHS
Manual wash booth provides a controlled environment for rinsing and washing off this residue.
MILD STEEL
Specification
| Material : | Mild Steel (Powder coated) |
| Size : | 6 Feet |
| Water Management System : | Yes |
| Spray Nozzles: | 18 (Stainless Steel 304 grade ) |
| Pump : | 1 Hp |
| Safety Features : | Splash Guards |
| Maintenance and Cleaning : | High (mild steel may degrade or react with certain chemicals, affecting the performance and longevity of the booth.) |
MANUAL WASH BOOTHS
STAINLESS STEEL
Manual wash booth provides a controlled environment for rinsing and washing off this residue.
SPECIFICATION
| Material : | Stainless Steel (304 Grade) |
| Size : | 6 Feet – 10 Feet |
| Water Management System : | Yes |
| Spray Nozzles: | 18 – 28 (Stainless Steel 304 grade ) |
| Pump : | 1 Hp |
| Safety Features : | Splash Guards |
| Maintenance and Cleaning : | Low (Stainless steel is a durable materials It is sturdy enough to withstand regular use and exposure to water and cleaning chemicals.) |
OUR PROCESS
How Do I USE HYDRO DIPPING FILMS?
STEPS 1
Prepare The Film
Carefully cut the hydro dip film to the appropriate size, ensuring that it is slightly larger than the object you plan to dip. This extra margin will allow for easier handling and alignment of the film during the dipping process.
STEPS 2
Laying Film In Water
Carefully cut the hydro dip film to the appropriate size, ensuring that it is slightly larger than the object you plan to dip. This extra margin will allow for easier handling and alignment of the film during the dipping process.
STEPS 3
Prepare For Film Activation
Use HGI film activator and directly fill the activator in your spray gun
STEPS 4
Activate The Film
STEPS 5
Dipping The Object
Once the film is in place, quickly and evenly submerge the object into the water, allowing the film to wrap around its surface. Use gentle, fluid motions to ensure that the film adheres evenly to all areas of the object.
STEPS 6
Rinse The Object
After dipping the object, carefully remove it from the water and rinse it thoroughly with clean, fresh water to remove any excess film residue. This step helps to ensure that the final finish is clean and free of any leftover chemicals or debris from the dipping process.
STEPS 7
Apply Clear Coat
For added protection and a glossy finish, consider applying a clear coat sealant to the object once it has dried completely. This clear coat helps to seal and protect the printed design from scratches, fading, and other damage, extending the life of the finished product.
OVENS
Consistency is key in hydro dipping, especially when working on multiple items or batches. A drying oven provides consistent and controlled drying conditions, ensuring that each item undergoes the same drying process, which contributes to consistent and high-quality results.
SPECIFICATION
| Material : | Mild Steel (Painted) |
| Size : | 6 Feet |
| Heating : | 18 KWA (Stainless Steel Element) |
| Blower : | 2 Hp |
| Pump : | 1 Hp |
| Safety Features : | Emergency shut-off switch, Auto cut-off |
| Maintenance and Cleaning : | Low |
